C&D Trojan (Shanghai) Energy Technologies Co., Ltd.

Series

Return to the product list page

Application

Features

12 years design life@ 25℃
True Front Access threaded copper alloy inserts, for reduced maintenance and increased safety
Terminal versatility - ease of diagnostic readings with C&D Ohmic Ring®
Innovative front terminal design maximizing energy density with direct connect extrusion fusion weld technology
Reduced headspace driving higher energy density, in cabinet or rack applications
Thermally welded case to cover bond to ensure a leak-proof seal
Flame-retardant polypropylene case and cover compliant with UL94 VO with an Oxygen Limiting Index of greater than 28
Absorbent Glass Mat (AGM) technology for efficient gas recombination of over 99%

Removable handles for ease of installation
Flame-arresting, one-way pressure-relief vent for safety and long life
Complies with UL 1778, 924, 1989 和 94 V-0, BS6290-4, IEC60896
UL-recognized component
Multicell design for ease of installation and maintenance
Not restricted for air transport - Complies with IATA/ICAO Special Provision A67
Not restricted for surface transport - Classified as non-hazardous material as related to DOT-CFR Title 49 parts 171-189
3 Year Full Warranty (refertowarrantycard,41-9027)
Not restricted for water transport - Classified as non-hazardous material IMDG Amendment 27

Specifications

*All dimensions are for reference only. Contact a C&D Representative for complete dimensional information.
